Popis
|
Performance |
|
|
AC Input: |
115-230V |
|
Frequency: |
50 – 60Hz |
|
+5V: |
18A |
|
+3,3V: |
18A |
|
+5V & +3,3V combined: |
90W |
|
+12V 1: |
41,68A |
|
+12V 2: |
N/A |
|
+12V 1 & +12V 2 combined: |
N/A |
|
+12V 3: |
N/A |
|
+12V 4: |
N/A |
|
+12V 3 & +12V 4 combined: |
N/A |
|
P.F.: |
>0,9 |
|
-12V: |
0,3A |
|
+5VSB: |
2,5A |
|
Maximum Load: |
500W |
|
Native cable |
|
|
24PIN ATX: |
1 |
|
SATA: |
6 |
|
MOLEX: |
2 |
|
Floppy: |
– |
|
4PIN 12V: |
– |
|
8PIN 12V: |
– |
|
8PIN (4+4) 12V: |
1 |
|
6PIN PCIe: |
– |
|
8PIN (6+2) PCIe: |
2 |
|
Features |
|
|
Spezification: |
ATX 12V 2.3 |
|
Form factor: |
PS II |
|
Efficiency: |
> 85% |
|
Dimension (DxWxH): |
140 mm x 150 mm x 87 mm |
|
PFC: |
Active PFC (0,9) |
|
Fan: |
120mm silent fan |
|
Security: |
UVP (Undervoltage protection) |
|
OVP (Overvoltage protection) |
|
|
SCP (Short-circuit protection) |
|
|
OPP (Overload protection) |
|
|
OCP (Overcurrent protection) |
|
|
OTP (Over Temperature Protection) |
|
|
AFC (Automatic Fanspeed Control) |
|
|
Warranty: |
24 Month |
